Key Features :
• Precision digital drives offer a maintenance-free high-accuracy motor and graphical interface that makes setup and operation easier than ever
• Graphical LCD shows four operating modes continuous run, timed dispense, copy dispense, volume dispense. View pump performance continually.
• Menu-driven interface lets you select one of seven languages for programming and operation
• Dispense by mL – volume in mL of each dispense, 0.001 to 9999 mL; Copy – 1 to 9,999 dispense cycles; or Time – time interval of on/off cycles (1 sec to 99 hr, 59 min, 59 sec per cycle)
• Brushless, maintenance-free motor offers ±0.1% speed control accuracy with a 6000 to 1 turndown ratio
• Remote control via DB25 female connector on drive:
– Speed control input 0 to 20 mA, 4 to 20 mA, or 0 to 10 V;
– Pumping direction requires open collector or contact closure;
– Start/stop/purge requires open collector or contact closure;
– Tachometer output 0 to 20 mA, 4 to 20 mA, or 0 to 10 V, open collector
• 2 years warranty
